Industrial RO Membranes
Brackish Water Series
High-rejection spiral-wound RO elements for industrial process water, boiler feed, municipal treatment, and Zero Liquid Discharge applications. Available in 4-inch and 8-inch formats.
Engineered for Industrial Reliability
TL Environment's Industrial RO Membrane series is built on a polyamide thin-film composite (TFC) structure, delivering consistent high rejection performance across a broad range of feed water chemistries. The series covers standard brackish water applications (BWRO), fouling-resistant variants for high-SDI feeds, and high-recovery elements optimized for ZLD pre-treatment systems.
All elements are manufactured to ISO 9001 quality standards with 100% pressure testing before shipment. Each batch is accompanied by a factory test report documenting actual permeate flow and salt rejection values — not nominal specifications.
The 8-inch (8040) format is the industry standard for large-scale industrial systems and is compatible with all major pressure vessel manufacturers. Custom configurations including 4-inch elements for pilot systems and skid-mounted packages are available on request.
Product Specification Table
Test conditions: 2,000 ppm NaCl, 25°C, pH 7.5, 15% recovery. Permeate flow ±15%. Salt rejection is minimum value.
| MODEL | ELEMENT SIZE | ACTIVE AREA | SALT REJECTION | PERMEATE FLOW | OPERATING PRESSURE | MAX FEED TEMP | TYPICAL APPLICATION |
|---|---|---|---|---|---|---|---|
| TL-BW-4040 | 4" × 40" | 7.9 m² | ≥99.5% | 9.5 m³/d | 1.55 MPa | 45°C | Light industrial, lab systems |
| TL-BW-8040 | 8" × 40" | 37.2 m² | ≥99.5% | 40.0 m³/d | 1.55 MPa | 45°C | Industrial process water, boiler feed |
| TL-FR-8040 | 8" × 40" | 37.2 m² | ≥99.2% | 42.0 m³/d | 1.38 MPa | 45°C | Fouling-resistant, high-SDI feeds |
| TL-HR-8040 | 8" × 40" | 37.2 m² | ≥99.7% | 36.0 m³/d | 1.72 MPa | 45°C | High-recovery systems, ZLD pre-treatment |
* Specifications subject to change. Contact our technical team for the latest product datasheets and project-specific selection guidance.
Designed for Industrial Demands
High Salt Rejection
Nominal NaCl rejection ≥99.5% under standard test conditions (2,000 ppm NaCl, 1.55 MPa, 25°C, pH 7.5, 15% recovery).
Wide pH Tolerance
Operating pH range 2–11; cleaning pH range 1–13. Suitable for aggressive industrial feed water chemistries.
Chlorine Resistance
Polyamide thin-film composite membrane with enhanced oxidant tolerance. Compatible with standard CIP protocols.
Consistent Performance
Tight manufacturing tolerances ensure element-to-element consistency across large project orders. Batch testing available.
Standard 8-Inch Format
Industry-standard 8-inch diameter elements are compatible with all major pressure vessel brands including Codeline, Pentair, and Protec.
Export-Ready Packaging
Each element is individually vacuum-sealed, pressure-tested, and packaged for international shipping. Shelf life: 12 months sealed.
Where Industrial RO Membranes Are Used
Need Product Selection Assistance?
Our technical team can help you select the right element configuration for your feed water chemistry, recovery target, and system design. Contact us for a project-specific recommendation.
